York MILLENIUM YCAS Series - Page 73

73
YORK INTERNATIONAL
FORM 201.18-NM6
DIMENSIONS – YCAS0283-0343 (SI)
7
635
584
DD
3755
708
400
2438
X
Z
G
C
1772
A
A
8"8"
3524
2705
2108
(EACH SIDE)
RIGGING HOLES
(2) 57 DIA.
SYS.#2SYS.#1
WATER OUTLET WATER INLET
76
648
648
787
2235
32
32
G
606
11561156
Y
X
C
POWER POWER
CONTROL/OPTIONS PANEL
FOR SYS. 2
POWER ELEMENTS
FOR SYS. 1
POWER ELEMENTS
DISTRIBUTION
ORIGIN
VIEW D-D
MOUNTING
16 DIA.
HOLES (TYP.)
APPROX. OPERATING WEIGHT
(KG)
ABC
DE F
LD04479
LD05207
CENTER OF GRAVITY (Copper)
YCAS X Y Z
0283 73.74 41.86 38.37
0303 73.84 41.72 38.09
0323 72.23 43.14 37.34
0343 73.32 43.06 37.21
CENTER OF GRAVITY (Alum.)
YCAS X Y Z
0283 72.93 41.63 35.51
0303 73.05 41.48 35.24
0323 71.32 43.05 34.54
0343 71.42 42.97 34.41
