York R-407C Optimized User Manual

96
YORK INTERNATIONAL
97
YORK INTERNATIONAL
FORM 201.19-EG4
SYSTEM #2 FIELD-SUPPLIED WIRING
FACTORY PROVIDED (LUGS)
MODEL
VOLTS MIN NF
WIRE RANGE
7
COMPRESSOR #4 FANS
11, 12
YCAS MCA
1
DISC SW
2, 9
STD. TERMINAL OPT. NF.
RLA Y-D-LRA XL-LRA RLA Y-D-LRA XL-LRA QTY
FLA LRA
MIN.
3, 5
MAX.
4, 6
BLOCK DISC SW. (EA.) (EA.)
380 171 200 225 250 # 2 - 4/0 #4 - 300 121 285 900 — — — 4 5.1 21.0
0218EB 460 146 150 175 225 # 2 - 4/0 # 2 - 4/0 100 228 719 — — — 4 5.2 29.0
575 115 150 150 175 # 2 - 4/0 # 2 - 4/0 80 182 574 — — — 4 3.9 25.9
380 171 200 225 250 1/0 - 300 #6 - 350 121 285 900 — — — 4 5.1 21.0
0248EB 460 146 150 175 225 # 2 - 4/0 # 2 - 4/0 100 228 719 — — — 4 5.2 29.0
575 115 150 150 175 # 2 - 4/0 # 2 - 4/0 80 182 574 — — — 4 3.9 25.9
380 227 250 300 350 1/0 - 300 #6 - 350 165 343 1093 — — — 4 5.1 21.0
0268EB 460 192 200 250 300 # 2 - 4/0 #4 - 300 137 280 893 — — — 4 5.2 29.0
575 152 150 200 250 # 2 - 4/0 # 2 - 4/0 109 224 714 — — — 4 3.9 25.9
380 227 250 300 350 1/0 - 300 #6 - 350 166 343 1093 — — — 4 5.1 21.0
0288EB 460 193 200 250 300 # 2 - 4/0 #4 - 300 137 280 893 — — — 4 5.2 29.0
575 152 150 200 250 # 2 - 4/0 # 2 - 4/0 109 224 714 — — — 4 3.9 25.9
380 264 400 350 450 2/0 - 500 (2) 3/0 - 250 195 343 1093 — — — 5 5.1 21.0
0308EB 460 222 250 300 350 1/0 - 300 #4 - 300 161 280 893 — — — 5 5.2 29.0
575 177 200 225 300 # 2 - 4/0 #6 - 350 129 224 714 — — — 5 3.9 25.9
380 264 400 350 450 2/0 - 500 (2) 3/0 - 250 195 343 1093 — — — 5 5.1 21.0
0328EB 460 222 250 300 350 1/0 - 300 #4 - 300 161 280 893 — — — 5 5.2 29.0
575 177 200 225 300 # 2 - 4/0 #6 - 350 129 224 714 — — — 5 3.9 25.9
380 414 600 500 500 (2) 1/0 - 300 (2) 250-500 166 343 1093 166 343 1,093 8 5.1 21.0
0358EB 460 352 400 400 450 2/0 - 500 (2) 3/0 - 250 138 280 893 138 280 893 8 5.2 29.0
575 277 400 350 350 2/0 - 500 (2) 3/0 - 250 109 224 714 109 224 714 8 3.9 25.9
380 460 600 600 600 (2) 1/0 - 300 (2) 250-500 194 343 1093 166 343 1,093 9 5.1 21.0
0398EB 460 392 600 450 500 2/0 - 500 (2) 3/0 - 250 162 280 893 138 280 893 9 5.2 29.0
575 309 400 350 400 2/0 - 500 (2) 3/0 - 250 129 224 714 109 224 714 9 3.9 25.9
380 513 600 600 700 (2) 2/0 - 500 (2) 250-500 196 343 1093 213 343 1,093 9 5.1 21.0
0418EB 460 434 600 500 600 (2) 1/0 - 300 (2) 250-500 162 280 893 176 280 893 9 5.2 29.0
575 344 400 400 450 2/0 - 500 (2) 3/0 - 250 129 224 714 141 224 714 9 3.9 25.9
