FORM 201.19-EG4
OPTIONAL SINGLE-POINT POWER SUPPLY WITH INDIVIDUAL SYSTEM CIRCUIT BREAKERS –
2 COMPRESSOR UNITS (SEE FIG. 2)
(One Field Provided Power Supply Circuit to the chiller. Field connections to Factory Provided Terminal Block (standard) or Non-Fused Disconnect (option)
in ‘Option Panel’. Individual System Circuit Breakers in each Motor Control Center
10
)
Electrical Data (continued)
CHILLER
FIELD-SUPPLIED WIRING
MODEL
VOLTS
FIELD PROVIDED POWER SUPPLY FACTORY PROVIDED (LUGS) WIRE RANGE
7
YCAS
MIN NF OVER-CURRENT PROTECTION
13
STANDARD OPTIONAL NF
MCA
1
DISC SW
2, 9
MIN.
3, 5
MAX.
4, 6
TERMINAL BLOCK DISC. SWITCH
200 427 600 500 500 (2) 1/0 - 300 (2) 250 - 500
230 376 400 450 500 (2) # 2 - 4/0 (2) 3/0 - 250
0098EB 380 228 250 250 300 1/0 - 300 # 6 - 350
460 188 200 225 250 # 2 - 4/0 # 6 - 350
575 151 200 175 200 1/0 - 300 # 6 - 350
200 536 600 700 800 (2) 2/0 - 500 (2) 250 - 500
230 471 600 600 700 (2) 1/0 - 300 (2) 250 - 500
0118EB 380 285 400 350 400 2/0 - 500 (2) 3/0 - 250
460 236 250 300 350 1/0 - 300 # 6 - 350
575 189 200 225 250 1/0 - 300 # 6 - 350
200 516 600 600 700 (2) 2/0 - 500 (2) 250 - 500
230 454 600 600 600 (2) 1/0 - 300 (2) 250 - 500
0128EB 380 275 400 350 350 2/0 - 500 (2) 3/0 - 250
460 228 250 300 300 1/0 - 300 # 6 - 350
575 182 200 225 250 1/0 - 300 # 6 - 350
200 589 800 700 800 (2) 2/0 - 500 (3) 2/0 - 400
230 517 600 600 700 (2) 2/0 - 500 (2) 250 - 500
0138EB 380 313 400 350 400 2/0 - 500 (2) 3/0 - 250
460 259 400 300 350 2/0 - 500 (2) 3/0 - 250
575 206 250 250 250 1/0 - 300 # 6 - 350
200 590 800 700 800 (2) 2/0 - 500 (3) 2/0 - 400
230 518 600 600 700 (2) 2/0 - 500 (2) 250 - 500
0148EB 380 313 400 350 400 2/0 - 500 (2) 3/0 - 250
460 260 400 300 350 2/0 - 500 (2) 3/0 - 250
575 207 250 225 250 1/0 - 300 # 6 - 350
200 699 800 800 1000 (3) 1/0 - 300 (3) 2/0 - 400
230 613 800 700 800 (2) 2/0 - 500 (3) 2/0 - 400
0158EB 380 371 400 450 500 (2) # 2 - 4/0 (2) 3/0 - 250
460 308 400 350 400 2/0 - 500 (2) 3/0 - 250
575 244 250 300 350 2/0 - 500 # 6 - 350
200 786 1000 1000 1000 (3) 2/0 - 500 (4) 250 - 500
230 688 800 800 800 (3) 1/0 - 300 (3) 2/0 - 400
0178EB 380 418 600 500 500 (2) 1/0 - 300 (2) 250 - 500
460 347 400 400 450 (2) # 2 - 4/0 (2) 3/0 - 250
575 275 400 350 350 2/0 - 500 (2) 3/0 - 250
200 848 1000 1000 1200 (3) 2/0 - 500 (4) 250 - 500
230 744 800 1000 1000 (3) 1/0 - 300 (3) 2/0 - 400
0198EB 380 451 600 600 600 (2) 1/0 - 300 (2) 250 - 500
460 374 400 450 500 (2) # 2 - 4/0 (2) 3/0 - 250
575 297 400 350 400 2/0 - 500 (2) 3/0 - 250
200 927 1000 1200 1200 (3) 2/0 - 500 (4) 250 - 500
230 812 1000 1000 1200 (3) 2/0 - 500 (4) 250 - 500
0208EB 380 493 600 600 600 (2) 1/0 - 300 (2) 250 - 500
460 408 600 500 500 (2) 1/0 - 300 (2) 250 - 500
575 325 400 400 400 2/0 - 500 (2) 3/0 - 250
See page 105 for Electrical Data footnotes.
