York STELLAR PLUS E*FH018 - Cooling Capacity - Furnace Matches; Performance Tables

036-21031-004 Rev. A (0603)
Unitary Products Group 5
* Requires a 2FD Blower Time Delay unless a standard furnace is equipped with one.
** Refer to Quick Selection Chart for specific furnace match-up.
COOLING CAPACITY - With Upflow, Downflow and Horizontal Furnace and Coils
UNIT
MODEL
FURNACE**
COIL
MODEL
COOLING
NOMINAL
AIRFLOW
W
RATED
CFM
NET MBH
SEER
W/O TXV
SEER + TXV
1
1. TXV = Use 1TV700 Series Kit.
EER
TOTAL SENS.
E4FH018S06
575
725
14,17 G1FA024S14,17 650 18.8 14.1 12.00 - 10.55
14 G1FA030S14 650 19.0 14.3 12.50 - 10.65
14,17 G1UA024S14,17 650 18.8 14.1 12.00 - 10.55
14 G1UA030S14 650 19.0 14.3 12.50 - 10.65
14,17 G2FD024S14,17 650 19.0 14.3 12.50 - 10.65
17 G2FD030(S,H)17 650 19.2 14.4 12.50 - 10.70
14 G2FD035(S,H)14 650 19.2 14.4 12.50 - 10.70
E4FH024S06
725
925
14 G1FA030S14 800 22.2 16.7 - 12.00 10.85
G1UA030S14 800 22.2 16.7 - 12.00 10.85
17,21 G1FA036S17,21 800 22.4 16.8 - 12.10 11.00
G1UA036S17,21 800 22.4 16.8 - 12.10 11.00
- G1HD024 820 23.6 17.7 12.10 - 10.85
17 G2FD024(S,H)14,17 820 23.6 17.7 12.10 - 10.85
17 G2FD030(S,H)17 820 23.6 17.7 12.10 - 11.00
14 G2FD035(S,H)14 820 23.6 17.7 12.10 - 11.00
E4FH030S06
925
1175
14 G1FA036S14 1050 28.2 21.2 - 12.00 10.35
17,21 G1FA036S17,21 1050 28.2 21.2 - 12.00 10.35
- G1HD036 1035 28.8 21.6 - 12.00 10.30
14 G1UA036S14 1050 28.2 21.2 - 12.00 10.35
17,21 G1UA036S17,21 1050 28.2 21.2 - 12.00 10.35
17 G2FD030(S,H)17 1050 28.2 21.2 - 12.00 10.35
17 G2FD030(S,H)17 1050 28.2 21.2 - 12.00 10.35
14 G2FD035(S,H)14 1050 28.6 21.5 - 12.00 10.35
17 G2FD036(S,H)17 1050 28.8 21.6 - 12.00 10.65
21 G2FD036(S,H)21 1050 28.8 21.6 - 12.00 10.65
E4FH036S06
1075
1375
17 G1FA048S17 1225 35.0 25.9 - 12.10 10.60
21 G1FA048S21 1225 35.4 26.2 - 12.50 10.70
17 G1UA048S17 1225 35.0 25.9 - 12.10 10.60
21 G1UA048S21 1225 35.4 26.2 - 12.50 10.70
17 G2FD036(S,H)17 1200 34.6 26.2 - 12.00 10.50
21 G2FD036(S,H)21 1200 34.6 26.2 - 12.00 10.50
21 G2FD042(S,H)21 1225 34.8 25.8 - 12.20 10.55
17 G2FD046(S,H)17 1225 35.0 25.9 - 12.10 10.60
E4FH042S06
1275
1625
17 G1FA048S17 1450 40.5 30.0 - 12.25 10.65
21 G1FA048S21 1450 40.5 30.0 - 12.40 10.70
17 G1UA048S17 1450 40.5 30.0 - 12.25 10.65
21 G1UA048S21 1450 40.5 30.0 - 12.40 10.70
21 G2FD042(S,H)21 1450 40.0 29.6 - 12.00 10.50
17 G2FD046(S,H)17 1450 40.5 30.0 - 12.25 10.65
21,24 G2FD048(S,H)21,24 1450 41.0 30.3 - 12.40 10.80
E5FH048S06
1400
1800
21 G1FA048S21 1600 46.5 34.9 - 12.00 10.45
21,24 G1FA060S21,24 1650 47.5 35.6 - 12.20 10.60
21 G1UA048S21 1600 46.5 34.9 - 12.00 10.45
21,24 G1UA060S21,24 1650 47.5 35.6 - 12.20 10.60
21,24 G2FD048(S,H)21,24 1600 47.5 35.6 - 12.00 10.50
24 G2FD060(S,H)24 1625 48.0 36.0 - 12.50 10.80
E4FH060S06
1600
2100
21,24 G1FA060S21,24 1850 57.0 41.0 - 11.70 10.40
21,24 G1UA060S21,24 1850 57.0 41.0 - 11.70 10.40
24 G2FD060(S,H)24 1800 58.0 42.0 - 12.00 10.70
24 G2FD061H24 1800 58.5 41.5 - 12.20 10.70
