York STELLAR PLUS E*FH018 - Heating Performance - Furnace Matches; Performance Tables

036-21031-004 Rev. A (0603)
Unitary Products Group 7
COP equals MBH output divided by (total KW input x 3.412).
HSPF (Heating Seasonal Performance Factor) is the total heating output during a normal annual usage period for heating divided by the total electric
power input during the same period.
— = Not Applicable.
HEATING PERFORMANCE - Furnace Coils
UNIT
MODEL
COIL
1
MODEL
1. Rated CFM same as for cooling.
ARI HEATING
2
2. Heating MBH based on ARI standards of 70° DB entering indoor air, 72% RH outdoor air with 25 feet of interconnecting piping and no supplemental
electric heat operation.
OUTDOOR TEMP
3
3. Integrated heating capacities include the effect of defrost cycles in the temperature range where they occur.
47°F 17 °F HSPF -3 °F 7°F17°F27°F37°F47°F 57°F
MBH COP MBH COP STD. V. S. MBH KW MBH KW MBH KW MBH KW MBH KW MBH KW MBH KW
E*FH WITH (VARIABLE SPEED & STANDARD) FURNACE COILS
E4FH018
G1HD024 18 3.08 9.9 2.00 7.1 -- 6.2 1.1 9 1.15 9.9 1.25 13.6 1.4 16 1.5 18 1.6 20 1.75
G1FA024S17 19.0 3.24 11.4 2.16 7.6 -- 6.6 1.09 9.2 1.1 11.4 1.25 13.8 1.45 16.6 1.54 19.6 1.64 22 1.74
G1UA024S17 19.0 3.24 11.4 2.16 7.6 -- 6.6 1.09 9.2 1.1 11.4 1.25 13.8 1.45 16.6 1.54 19.6 1.64 22 1.74
G1FA030S14 19.0 3.32 11.6 2.20 7.6 -- 6.6 1.08 9.2 1.15 11.6 1.27 14.2 1.43 16.8 1.5 19.8 1.62 22.4 1.76
G1UA030S14 19.0 3.32 11.6 2.20 7.6 -- 6.6 1.08 9.2 1.15 11.6 1.27 14.2 1.43 16.8 1.5 19.8 1.62 22.4 1.76
E4FH024
G1HD024 24 3.16 12.2 2.00 8 -- 7.2 1.57 10 1.67 12.2 1.76 16.4 1.9 19.6 1.95 24 2.05 27.4 2.17
G1FA030S17 23.6 3.16 13.4 2.14 8 -- 7.6 1.5 10.4 1.65 13.4 1.76 16.6 1.85 19.8 1.97 23.6 2.03 27.6 2.16
G1UA030S17 23.6 3.16 13.4 2.14 8 -- 7.6 1.5 10.4 1.65 13.4 1.76 16.6 1.85 19.8 1.97 23.6 2.03 27.6 2.16
G1FA036S17,21 24 3.26 13.6 2.18 8 -- 7.6 1.52 10.4 1.6 13.6 1.76 16.8 1.9 20 1.9 24 2.03 28.2 2.18
G1UA036S17,21 24 3.26 13.6 2.18 8 -- 7.6 1.52 10.4 1.6 13.6 1.76 16.8 1.9 20 1.9 24 2.03 28.2 2.18
E4FH030
G1HD036 28 3.33 17 2.3 8 -- 9.8 2.08 13.1 2.14 16.6 2.1 19.8 2.2 23.8 2.38 28 2.5 39.8 2.55
G1FA036S14 28 3.33 17.2 2.3 8 -- 10 2.07 13.2 2.15 16.8 2.3 19.9 2.3 23.9 2.39 28 2.5 34 2.57
G1UA036S14 28 3.33 17.2 2.3 8 -- 10 2.07 13.2 2.15 16.8 2.3 19.9 2.3 23.9 2.39 28 2.5 34 2.57
G1FA036S17,21 28 3.33 17.2 2.3 8 -- 10.1 2.08 13.3 2.17 17 2.4 20.1 2.4 24.1 2.4 28 2.55 34.2 2.6
G1UA036S17,21 28 3.33 17.2 2.3 8 -- 10.1 2.08 13.3 2.17 17 2.4 20.1 2.4 24.1 2.4 28 2.55 34.2 2.6
E4FH036
G1FA048S21 35.6 3.46 21.8 2.30 8.0 -- 12.8 2.61 17.3 2.69 21.8 2.78 26.3 2.86 31.3 2.95 35.6 3.02 41.2 3.07
G1UA048S21 35.6 3.46 21.8 2.30 8.0 -- 12.8 2.61 17.3 2.69 21.8 2.78 26.3 2.86 31.3 2.95 35.6 3.02 41.2 3.07
G1FA048S17 36.0 3.38 21.8 2.26 8.0 -- 12.5 2.63 17.2 2.73 21.8 2.83 26.4 2.93 31.7 3.04 36.0 3.12 41.4 3.16
G1UA048S17 36.0 3.38 21.8 2.26 8.0 -- 12.5 2.63 17.2 2.73 21.8 2.83 26.4 2.93 31.7 3.04 36.0 3.12 41.4 3.16
E4FH042
G1FA048S21 42.0 3.50 25.2 2.30 8.0 -- 12.5 2.98 18.9 3.09 25.2 3.21 31.5 3.33 38.5 3.47 42.0 3.52 50.3 3.66
G1UA048S21 42.0 3.50 25.2 2.30 8.0 -- 12.5 2.98 18.9 3.09 25.2 3.21 31.5 3.33 38.5 3.47 42.0 3.52 50.3 3.66
G1FA048S17 41.5 3.40 25.0 2.24 8.0 -- 13.4 3.05 19.2 3.16 25.0 3.27 30.8 3.38 37.3 3.51 41.5 3.58 47.8 3.66
G1UA048S17 41.5 3.40 25.0 2.24 8.0 -- 13.4 3.05 19.2 3.16 25.0 3.27 30.8 3.38 37.3 3.51 41.5 3.58 47.8 3.66
E5FH048
G1FA048S21 48 3.40 28 2.30 8 -- 16.1 3.23 22.1 3.41 28 3.57 34 3.72 40.6 3.91 48 4.06 54.8 4.16
G1UA048S21 48 3.40 28 2.30 8 -- 16.1 3.23 22.1 3.41 28 3.57 34 3.72 40.6 3.91 48 4.06 54.8 4.16
G1FA060S21,24 48 3.40 28 2.30 8 -- 16.2 3.24 22.2 3.42 28 3.55 34 3.7 40.6 3.92 48 4 54.9 4.18
G1UA060S21,24 48 3.40 28 2.30 8 -- 16.2 3.24 22.2 3.42 28 3.55 34 3.7 40.6 3.92 48 4 54.9 4.18
E4FH060
G1FA060S21,24 60.0 3.40 40.0 2.40 8.0 -- 18.9 3.95 26.0 4.21 33.0 4.48 40.1 4.74 48.1 5.04 57.0 5.39 67.8 5.60
G1UA060S21,24 60.0 3.40 40.0 2.40 8.0 -- 18.9 3.95 26.0 4.21 33.0 4.48 40.1 4.74 48.1 5.04 57.0 5.39 67.8 5.60
