York STELLAR PLUS E*FH018 - Heating Performance - Air Handler Matches; Performance Tables

036-21031-004 Rev. A (0603)
6 Unitary Products Group
HEATING PERFORMANCE - Air Handler and Multi-position Coils
UNIT
MODEL
COIL
1
MODEL
ARI HEATING
2
OUTDOOR TEMP
3
47 °F 17 °FHSPF-3 °F 7°F17°F27°F37°F47°F57°F
MBH COP MBH COP STD. V. S. MBH KW MBH KW MBH KW MBH KW MBH KW MBH KW MBH KW
E4FH018
F2RP/F2FP018 17 3.00 10 2.00 6.8 -- 4 1.3 7.8 1.27 10 1.35 12.3 1.60 15.2 1.6 17 1.61 17.6 1.66
F2RP/F2FP024 19.5 3.20 11.3 2.10 7.5 -- 4.5 1.25 8 1.25 11.3 1.36 12.7 1.57 15.5 1.68 19.5 1.59 19.6 1.65
G2FD024(S,H)14,17 19.0 3.32 11.6 2.00 7.6 8 6 1.51 8 1.25 11.6 1.36 12.9 1.40 16.5 1.52 19.8 1.59 19.6 1.65
G2FD030(S,H)17 19.8 3.40 1.16 2.24 7.5 -- 6.2 1.52 8.2 1.23 11.6 1.69 12.8 1.38 16.4 1.5 19.8 1.79 19.6 1.63
G2FD035(S,H)14 19.8 3.40 1.16 2.24 7.5 -- 6.2 1.5 8.2 1.25 11.6 1.69 12.9 1.39 16.6 1.51 19.8 1.79 19.8 1.64
E4FH024
F2RP/F2FP024 24 3.32 12.9 2.20 8 -- 6.6 1.55 11 1.78 12.9 1.7 16 1.85 18.8 1.87 24 1.8 26.6 2.07
F2RP/F2FP030 24 3.32 12.9 2.20 8 -- 6.8 1.56 11.4 1.76 12.9 1.78 16.2 1.84 19 1.85 24 2.07 26.8 2.08
G2FD024(S,H)14,17 23.8 3.40 13.5 2.30 8 8.1 6.6 1.58 11.6 1.75 13.5 1.78 16.3 1.82 19.1 1.85 23.8 2.07 26.6 2.1
G2FD030(S,H)17 24 3.26 13.6 2.18 8 -- 6.8 1.6 11.4 1.73 13.6 1.75 16.2 1.80 19.2 1.83 24 2.08 26.8 2.08
G2FD035(S,H)14 24 3.26 13.6 2.18 8 -- 6.9 1.57 11.6 1.74 13.6 1.77 16.4 1.80 19.4 1.8 24 2.06 26.8 2.1
E4FH030
F2RP/F2FP030 28 3.33 17 2.33 8 -- 9.6 1.98 13.1 2.1 16.6 2.21 20.3 2.33 24.3 2.46 28 2.56 32.9 2.7
F2RP/F2FP036 28 3.33 17 2.33 8 -- 9.6 1.95 13.1 2.09 16.7 2.21 20.2 2.34 24.4 2.48 28 2.57 33 2.71
G2FD030(S,H)17 28 3.33 17 2.33 8 8.2 9.8 2.06 13.1 2.14 16.5 2.2 19.9 2.29 23.9 2.4 28 2.5 32.7 2.55
G2FD035(S,H)14 28 3.33 17 2.33 8 -- 9.4 2.06 13.2 2.14 16.6 2.3 20 2.31 24 2.41 28 2.6 33 2.6
G2FD036(S,H)17,21 28 3.33 17 2.33 8 8.2 9.9 2.02 13.3 2.15 16.6 2.19 21 2.41 23.8 2.4 28 2.6 33.4 2.65
E4FH036
F2RP/F2FP036 36.0 3.10 21.8 2.30 8.0 -- 12.5 2.36 17.1 2.57 21.8 2.78 26.5 2.99 31.7 3.21 36.0 3.40 41.4 3.56
F2RP/F2FP042 36.0 3.10 21.8 2.30 8.0 -- 12.5 2.35 17.2 2.57 21.8 2.78 26.4 2.99 31.6 3.21 36.0 3.40 41.5 3.57
G2FD042(S,H)21 36.0 3.38 21.8 2.26 8.0 -- 12.5 2.63 17.1 2.73 21.8 2.83 26.5 2.93 31.7 3.04 36.0 3.12 41.7 3.18
G2FD046(S,H)17 36.0 3.38 21.8 2.26 8.0 -- 12.5 2.63 17.2 2.73 21.8 2.83 26.4 2.93 31.7 3.04 36.0 3.12 41.4 3.16
G2FD036(S,H)17,21 36.0 3.40 21.8 2.28 8.0 8.1 12.5 2.60 17.1 2.70 21.8 2.80 26.5 2.90 31.7 3.02 36.0 3.10 41.7 3.16
E4FH042
F2RP/F2FP042 42.0 3.30 25.2 2.20 7.8 -- 13.4 3.08 19.3 3.22 25.2 3.36 31.1 3.50 37.7 3.63 42.0 3.73 48.5 3.85
F2FP048 42.0 3.58 25.2 2.32 8.0 -- 12.5 2.98 18.8 3.08 25.2 3.18 31.6 3.29 38.6 3.40 42.0 3.44 50.4 3.56
G2FD042(S,H)21 41.5 3.40 25.0 2.26 8.0 8.1 12.5 2.94 18.8 3.09 25.0 3.24 31.2 3.39 38.2 3.55 41.5 3.58 49.6 3.73
G2FD046(S,H)17 41.5 3.40 25.0 2.24 8.0 -- 13.4 3.05 19.2 3.16 25.0 3.27 30.8 3.38 37.3 3.51 41.5 3.58 47.8 3.66
G2FD048(S,H)21,24 42.0 3.58 25.2 2.32 8.0 8.0 12.4 2.98 18.8 3.08 25.2 3.18 31.6 3.29 38.7 3.41 42.0 3.44 50.4 3.56
E5FH048
F2FP048 47.5 3.30 28.4 2.20 8.1 -- 17 3.54 22.6 3.66 28.4 3.78 34.2 3.91 39 3.76 47.5 4.03 53.5 4.13
F2FP060 47.5 3.30 28 2.20 8.1 -- 18 3.5 22.8 3.58 28 3.75 34.6 3.95 40 3.8 47.5 4.15 54 4.3
G2FD048(S,H)21,24 48 3.48 28 2.34 8.1 8.2 17 3.52 22.6 3.6 28 3.76 34.2 3.96 40 3.9 48 4.04 53.5 4.25
G2FD060(S,H)24 48.5 3.30 28.4 2.20 8.1 8.2 18 3.55 22.8 3.65 28.4 3.78 34.6 3.96 40 3.8 48.5 4.03 54 4.26
E4FH060
F2FP060 60.0 3.40 40.0 2.40 8.0 -- 18.7 4.08 26.1 4.44 40.0 4.80 40.7 5.16 49.0 5.55 60.0 5.94 68.6 6.25
F2FV060 60.0 3.00 40.0 2.60 -- 8.3 17.6 3.93 24.6 4.11 40.0 4.29 38.6 4.47 46.6 4.68 60.0 4.93 66.1 5.07
G2FD060(S,H)24 60.0 3.50 40.0 2.50 8.2 8.3 18.9 3.94 26.0 4.21 40.0 4.48 40.0 4.75 48.1 5.05 60.0 5.39 67.8 5.61
G2FD061H24 62.0 3.60 41.0 2.60 8.4 – 20.2 4.07 26.9 4.28 41.0 4.49 40.5 4.70 48.3 4.95 62.0 5.22 67.5 5.39
For Notes See Page 7.
