York SUNLINE 2000 B1HN090 - Electrical Data; Field Wiring

MODEL
POWER
SUPPLY
COMPRESSOR
(#1 and #2)*
OUTDOOR
FAN
MOTOR,
(#1 & #2)
FLA
EACH
SUPPLY
AIR
BLOWER
MOTOR,
FLA
TOTAL
UNIT
AMPACITY,
AMPS
MAXIMUM
FUSE
SIZE,
1,2
AMPS
RLA
EACH
LRA
EACH
2HP 3HP 2HP 3HP 2HP 3HP
BHN090
208/230-3-60
460-3-60
575-3-60
14.1
7.1
5.8
130
64
52
2.3
1.3
1.3
4
7.5
3.4
2.7
-
-
-
43.8
22.0
18.4
-
-
-
50
25
20
-
-
-
BHN120
208/230-3-60
460-3-60
575-3-60
17.3/16.7
9.6
8.3
150
73
59
3.5
2.5
2.5
4
-
-
-
10.6
4.8
3.9
-
-
-
55.9
31.4
27.6
-
-
-
70
40
35
*
Dual numbers shown as “17.3/16.7" indicates compressor #1 / #2 respectively.
NOTES: 1. Dual element, time delay type.
2. Maximum HACR breaker of the same AMP size is applicable, except 575 voltages.
3. Motor voltage (460-1-60). Unit includes 575/460V transformer.
ELECTRICAL DATA
VOLTAGE
LIMITATIONS*
POWER SUPPLY
VOLTAGE
MIN. MAX.
208/230-3-60 187 253
460-3-60 414 506
575-3-60 518 630
*
Utilization Range “A” in accordance with ARI Standard 110.
FIELD WIRING
511.17-TG2Y
Unitary Products Group 9
