COOLING CAPACITY - With Air Handler Coils
UNIT MODEL
AIR HANDLER
COIL
1
MODEL
COOLING
MODEL W STAGE
RATED
CFM
NET MBH
SEER EER
TOTAL SENSIBLE
1 PH HP WITH MV - VARIABLE SPEED
YZF02413(C)
MV12B 17 FC/MC35B 800 23.6 17.8 15.00 12.50
MV12B 17 FC/MC43B 800 24.0 18.6 16.00 13.00
YZF03013(C)
MV12B 17 FC/MC43B 1000 28.8 21.8 16.00 13.00
MV16C 21 FC/MC43C 1000 28.8 22.0 16.00 13.00
YZF03613(C)
MV12D 24 FC/MC48D 1160 34.8 26.0 15.00 12.50
MV16C 21 FC/MC48C 1200 34.6 25.8 15.00 12.50
MV12D 24 FC/MC60D 1135 34.6 25.6 15.00 12.50
YZF04213(C) MV20D 24 FC/MC62D 1400 41.0 28.0 15.00 12.50
YZF04813(C)
MV20D 24 FC/MC62D 1630 46.5 34.8 15.00 12.50
MV20D 24 FC64D 1630 48.0 36.8 15.00 12.50
YZF06013(C)
MV20D 24 FC/MC62D
1 1075 46.5 29.8
15.00
20.80
2 1630 56.0 39.0 11.80
MV20D 24 FC64D
1 1075 48.0 31.2
15.00
21.60
2 1630 57.5 40.5 12.00
1 PH HP WITH AV / SV / F*FV - VARIABLE SPEED
YZF02413(C) AV*36 21 – – 725 23.8 17.4 16.00 13.00
YZF03013(C) AV*36 21 – – 960 28.8 21.6 16.00 13.00
YZF03613(C) AV*48 24 – – 1220 35.2 26.6 15.00 12.50
1 PH HP WITH AHP/ SHP / AHX / F*FP
YZF02413(C)
AHX30 17 – – 835 23.8 18.1 15.00 12.50
AHX36 21 – – 820 24.0 18.1 15.00 12.50
F6FP030 17 – – 850 23.8 17.9 15.00 12.50
F6FP036 21 – – 855 23.8 18.0 15.00 12.50
YZF03013(C) AHX36 21 – – 1005 28.8 22.0 16.00 13.00
YZF03613(C)
AHX42 21 – – 1200 35.2 26.4 15.00 12.50
AHX48 24 – – 1255 35.4 27.2 15.00 12.50
F6FP042 24 – – 1290 35.2 27.2 15.00 12.50
F6FP048 24 – – 1125 34.8 25.6 15.00 12.50
YZF04213(C)
AHX60 24 – – 1440 41.5 28.0 15.00 12.50
F6FP060 24 – – 1475 41.5 28.6 15.00 12.50
YZF04813(C)
AHX60 24 – – 1570 46.5 35.2 15.00 12.50
F6FP060 24 – – 1570 46.5 35.0 15.00 12.50
YZF06013(C) AHX60 24 –
1 1255 48.0 31.6
15.00
20.65
2 1930 57.0 41.5 11.60
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ARI Standards 210.
Cooling MBH based on 8°F entering air temperature, 50% RH, and rated air flow.
EER (Energy Efficiency Ratio) is the total cooling output in BTU’s at 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTU’s during a normal annual usage period for cooling divided by the total electric power
input in watt-hours during the same period.
1. MC coils available with a factory installed horizontal drain pan. See price pages for specific model number.
