Step 6: Install the Handlebar Support
Required parts:
1. Connect the sensor wire of the bottom of the Handlebar Support (#9) with the sensor
wire of the Support Tube (#2).
2. Insert the Handlebar Support (#9) to the Support Tube (#2), secure with 4 Flat Washers
(#30) at the side, 2 Wave Washers (#29) at the front, and 6 Round Head Inner Hexagon
Bolts (#31), then tighten with Socket Head Screw Wrench S5 (#33).
1 Handlebar Support (#9) 2 Wave Washers (#29)
4 Flat Washers (#30) 6 Round Head Inner Hexagon Bolts (#31)
1 Socket Head Screw Wrench S5 (#33)
