Yowza Sebring - Page 12

12
YOWZA SEBRING TREADMILL
STEP1
ASSEMBLY
STEP2-A). Rotate the Uprights up to vertical position.
STEP2-B). Using the M8x58mm Bolt (837) to secure the upright
to frame by 6mm Allen Key(B).
STEP2-C). Attach the Upright fix bolt cover-right (221) to the frame, then
attach the Upright fix bolt cover-left (258) to the frame
837
X2
221
X2
258
X2
221
837
837
258
