EMC Information
Guidance and declaration of manufacturer -Electromagnetic
emission
Immunity test test level
Electrostatic discharge (ESD)
IEC 61000-4-2
±
8 kV contact
±15 kV Air
Electrical fast transient /bursts
IEC 61000-4-4
±2 kV for power supply lines
Surge
IEC 61000-4-5
±1 kV line to line
Voltage dips, short
interruptions and Voltage variations on
power supply input lines
IEC 61000-4-11
0% U
T
0.5 cycle at
0°,45°,90°,135°,180°,225°,270°and
315°
0% U
T
1 cycle
70% UT 25/30 cycles at 0°
Voltage short interruptions :
0% UT 250/300 cycles at 0°
Power frequency
(50 Hz) magnetic
IEC 61000-4-8
3
0 A/m
Radiated RF EM fields
IEC 61000-4-3
10V/m
80MHz – 2.7GHz
80% AM at 1kHz
Conducted disturbances induced by
RF fields
IEC 61000-4-6
3V/m
0.15MHz – 80MHz
6V in ISM and amateur radio bands
between 0.15MHz and 80MHz
80% AM at 1kHz
Note: U
T
is the a.c. mains voltage prior to application of the test level.
