PG 4
MANUAL Screen The Manual Screen control screen is where you can make
temporary changes to your CT100’s operation. From the Full HOME screen, touch the main
temperature display to use this screen. [See page 13 for details]
yyg
F
HOLD
EMER
HOLIDAY
HEAT
Target
Temperature
Room
Temperature
Return HOME
Temp Up / Temp Down arrows
Touch these to raise and lower
the manual override Target Temp.
HOLIDAY
Touch this to invoke a
single program that repeats day
after day until you turn it off.
Manual Override Indicator
Shows TEMPORARY when
you have modified the Target Temperature
EMER heat for
HEAT PUMP systems.
TEMPORARY
HOLD Touch this area to operate the thermostat as
a manual thermostat. It will keep the temperature
ou set until ou chan e it or cancel HOLD.
To Next Page
