PG 2
Control Screens
HOME Screen
Before you operate the CT100 please get familiar with these basic control screens. All the CT100
functions are accessed through these screens: HOME, MENU, PROGRAM and MANUAL. The
CT100 touch screen technology allows you to select (by touching) an item and change it using the +/-
arrows or the time arrows.
The HOME screen is displayed when
the unit is operating. Touching the
HOME icon on another screen
will always return you to this screen.
To set a Mode:
Press the mode button on the side.
The CT100 will step through the
modes HEAT, OFF, and COOL in
order. The LCD shows what mode
you are in.
DAY
F
LINK
RADIO
TARGET TEMP
1
COOL
AUTO
PM
Thermostat
Mode
Time
of day
Current Room
Temperature
Radio
indicator
Lock
status
Fan
status
Time
Slot
Target
Temperature
Day
To Next Page
