Zanussi ZDLN1521 - Filter and Spray Arm Cleaning; Filter System Cleaning

• Do not use abrasive products, abrasive
cleaning pads or solvents.
11.4 Cleaning the filters
The filter system is made of 3 parts.
C
B
A
1. Turn the filter (B) counterclockwise and
remove it.
2. Remove the filter (C) out of filter (B).
3. Remove the flat filter (A).
4. Wash the filters.
5.
Make sure that there are no residues of
food or soil in or around the edge of the
sump.
6. Put back in place the flat filter (A). Make
sure that it is correctly positioned under
the 2 guides.
7. Reassemble the filters (B) and (C).
8. Put back the filter (B) in the flat filter (A).
Turn it clockwise until it locks.
18 ENGLISH
