zapco Reference 360.4 - Reference 750.2 Specifications

31
Reference 750.2 Specifications
Total Power (14.4V @ 1kHz) Power
Rated Power / Channel T.H.D.+N
175watts x 2 @ 4Ω
< .04%
360 watts x 2 @ 2Ω
< .05%
Bridged Mono
780watts x 1 @ 4 Ω Mono
< .2%
Frequency Response 20 – 20kHz, + 0 / - .5dB
S/N Ratio > 90dB
Transient Distortion (4Ω, 40W)
< .03%
Slew Rate
40 V/µS
Damping Factor
> 1000 @ 4Ω
Input Sensitivity
Balanced (DIN) 560mV – 10V
Unbalanced (RCA) 260mV – 5V
Separation > 60dB
Max. Current Requirements 120 Amps @ 750 watts
Idle Current 1.56 Amps
Dimensions 23”L x 7.5”W x 1.95”H
