zapco Reference 750.2 - Reference 360.4 Specifications

49
Reference 360.4 Specifications
Total Power (14.4V @ 1kHz) Power
Dynamic (4Ω mono)
395 watts
.2% T.H.D. 365 watts
Rated Power / Channel T.H.D.+N
50 watts x 4 @ 4Ω
< .046%
90 watts x 4 @ 2Ω
< .13%
Bridged Mono
110 watts x 2 @ 8Ω
< .05%
180 watts x 2 @ 4Ω
< .1%
Frequency Response
20 – 20kHz, ± .12dB
S/N Ratio > 95dB
Transient Distortion (4Ω, 40W)
< .01%
Slew Rate
> 23 V/µS
Damping Factor
> 160 @ 4Ω
Input Sensitivity
Balanced (DIN) 500mV – 10V
Unbalanced (RCA) 250mV – 5V
Separation > 55Db Front, 58dB Rear
Max. Current Requirements 45 Amps @ 365 watts
Idle Current 1.1 Amps
Dimensions 18”L x 7.5”W x 1.95”H
