Page - 34/81 AFCZP0BC- COMBIACX & ACEX - User Manual
10 PROGRAMMING & ADJUSTMENTS USING
DIGITAL CONSOLE
10.1 Adjustments via console
4 To access and adjust all parameters it is necessary to use the Zapi console. Since
the COMBIACX/ACEX has no external serial connector, the Zapi console has to be
connected through a remote module, like a Zapi tiller card of a Zapi display. This
module has to be connected to the same Canbus line of the inverter.
4 Otherwise it is possible to connect a pc to the Canbus line and use the PC CAN
Console software. This tool is more powerful than the standard serial console.
The following paragraphs describe the controller configuration in the case the
operator is using the Zapi console.
10.2 Description of console (hand set) & connection
