12.4.2 Config menu “ADJUSTMENTS” functions list
To enter the CONFIG MENU it is necessary to push in the same time the right side
top and left side top buttons. Then roll until the ADJUSTMENTS item appears on the
hand set display. Push the ENTER button (see the Figure 12-6 below).
1) Opening Zapi Menu
EPSAC0 S ZP0.70
24V 50A 00000
2) Press Top Left & Right Buttons to enter
CONFIG MENU
% ' %
' ' '
3) The Display will show: SET MODEL
CONFIG MENU
SET MODEL
4) Press ROLL UP button until ADJUSTMENTS
MENU appears
% ' '
' ' '
5) ADJUSTMENTS appears on the display
CONFIG MENU
ADJUSTMENTS
6) Press ENTER to go into the ADJUSTMENTS
MENU
' % '
' ' '
7) The display will show:
ADJUSTMENT #01
LEVEL= 0
8) Press ROLL UP or ROLL DOWN button until
the desired parameter is reached
% ' '
% ' '
9) The desired parameter appears
SET SAT. FREQ.
100HZ
10) Press SET UP or SET DOWN button to modify
the adjustment
' ' %
' ' %
SET SAT. FREQ.
110HZ
11) Press OUT
' ' '
' % '
12) Press ENTER to confirm
' % '
' ' '
13) Repeat the same from 5 to 12 points for the
other adjustments
Figure 12–6
