Page 14 SEM1
4 PROGRAMMING AND SETTINGS USING A CONSOLE
4.1 SETTING BY CONSOLE
Adjustments of the parameters and the configurations are to be carried out by the pro-
grammable Console. The Console is connected to the relative connector B.
The connection is to be carried out with the key sw. open or the battery disconnected.
Pay attention to the connector polarity of the console when it is connected
to the controller.
4.2 PROGRAMMING CONSOLE FUNCTIONS
- Configuration Function.
- Parameter Settings.
- Tester - When the chopper is running, this function is not available.
In Standby Mode the following can be tested:
- Battery Voltage
- Internal Temperature of the Chopper
- Accelerator Potentiometer Wiper
- Forward Switch
- Reverse Switch
- Handle/Seat Switch
- Cut Back Switches 1 & 2
- Quick Inversion.
- Save Function - Saves Program Configuration.
- Restore Function - Restores Program Configuration.
- Alarms - Displays the last 5 Alarms together with the temperature and the hour
meter reading when the alarm occurred.
- Accelerator range programming, records the minimum and maximum output values
of the accelerator unit, optimising in this way the full stroke.
