Page - 20/50 AFGZP0BA – SMART CONSOLE - User Manual
As soon as you restart scrolling up or down the “blocked” variable will be placed
in first line from top: from now it will not move anymore but its current value will
be updated continuously as usual. The “blocked” variable will be highlighted in
light blue.
Blocking procedure can be repeated up to three time thus three variables can be
fixed on screen while the fourth one always scrolls. See example below.
In this way it is possible to keep track of four variables, placed far from one
another in the complete list, in a single view.
To “unblock” the last blocked variable, press LEFT button. Pressing LEFT up to
three times will unblock all variables
Press ESC to go back to MAIN MENU.
4 Notice that pressing F1 will activate graphical representation over time of the
selected variables
4 Graphic tester feature isn’t fully operative yet: it will be activated in a future
firmware.
