Zapi ZAPIMOS Series User Manual

Page 35
AUX
OUTPUT
STOP
ON
RAMP
A7 (Saab), B9 (Minifit)
OUTPUT
BEHAVIUR ON A SLOPE
BRAKE ON
-Drives the coil of a electromagnetic
brake.
-The hydraulic steering function
request is sent to the pump inverter
by the can-bus link
The truck is electrically hold on a
slope; when the time set by
"auxiliary time" parameter is elapsed
the brake is applied and the 3-
phase bridge is released. Do not
use this combination if the
negative brake is not instolled.
BRAKE OFF
-Drives the coil of a electromagnetic
brake.
-The hydraulic steering function
request is sent to the pump inverter
by the can-bus link
The truck is not electrically hold on
a slope, but comes down very
slowly; when the time set by
"auxiliary time" parameter is
elapsed, the brake is applied and
the 3-phase bridge is opened. Do
not use this combination if the
negative brake is not instolled.
HYDRO
CONT.
ON
-Drives the coil of a hydraulic
steering contactor.
-The hydraulic steering function
request is also sent to the pump
inverter by the can-bus link
The truck is electrically hold on a
slope; when the time set by
"auxiliary time" parameter is
elapsed, the truck comes down very
slowly, till the flat is reached.
HYDRO
CONT.
OFF
-Drives the coil of a hydraulic
steering contactor.
-The hydraulic steering function
request is also sent to the pump
inverter by the can-bus link
The truck is not electrically hold on
a slope, but comes down very
slowly till the flat is reached.
EXCL.
HYDRO
ON
-Drives the coil of a hydraulic
steering contactor.
-The hydraulic steering function
request is also sent to the pump
inverter by the can-bus link
The truck is electrically hold on a
slope; when the time set by
"auxiliary time" parameter is
elapsed, the truck comes down very
slowly, till the flat is reached.
EXCL.
HYDRO
OFF
-Drives the coil of a hydraulic
steering contactor.
-The hydraulic steering function
request is also sent to the pump
inverter by the can-bus link
The truck is not electrically hold on
a slope, but comes down very
slowly till the flat is reached.
