TRANSMIT MENU
UHF Transmitter Power Level Set
The UHF transmit power of the ZMT4 is set from this page. The transmit power can set to either 10 or
50mW.
UHF Transmit Modulation Set
The UHF transmission modulation is the way the ZMT4 sends audio to the receiver. The modulation format is
set from this menu. Please note if the transmission format that is set here, and the format set on the receiver
do not match, the receiver will be unable to decode the audio from the transmitter. Also note that after any
change to the transmit format the ZMT4 will need to be rebooted by pressing the card key before the new
format takes effect.
MONO
XR
ZHD 96
Modulation Bandwidth 200 kHz 200 kHz 96 kHz
Minimum Channel to Channel Spacing 400 kHz 400 kHz 200 kHz
6 MHz TV Channel Capacity 15 15 30
Latency 3.5ms 6ms 6ms
Transmitter Disable - Record only mode
• Record Only Mode - Will set the ZMT4 to act as a standalone recorder and will not transmit any audio over
UHF. This will conserve battery power since the transmitter is disabled.
• Normal TX Mode - Will allow the ZMT4 to both transmit audio and record on its internal micro-SD card.
TX FORMAT:
ZHD96
PRESS CARD TO REBOOT
TX DISABLE :
NORMAL TX MODE
TX POWER: 50MW
