Zaxcom ZMT4 Wiring Diagrams
26
Wiring Diagrams
The following 3-pin micro-LEMO connectors mate with the microphone connector:
• FGB.00.303.CLAD.22 – has a latch with a pull release.
• FVB.00.303.NLA – has a latch with a twist release.
Please note it is required that the ground gets attached to the shell of the LEMO connector.
Two Wire Lavalier Microphone Configuration
Three Wire Lavalier Microphone Configuration
Please contact the microphone manufaturer.
Microphone Input Configuration
To Next Page
