Load Ribbon
9/28/12 105SLPlus™ Quick Reference Guide P1056467-001
7. Thread the ribbon over the media dancer assembly (1) and under the ribbon guide roller
(
2).
8. Push the ribbon leader forward until it passes under the printhead assembly (1), over the
snap plate (2), and then over the platen roller (3).
2
1
1
3
2
