Getting To Know
Your Printer
Installation & Operation
2 980412-001 Rev.A
Media Access
Cover
(Lift to Open)
Lower Front Cover
(Lift Up & Out to Open)
Label Taken Sensor
Power Switch
& Cord Module
Interface
Connectors
Label Mode Switch
Media Sensor
and Guide
Print Head
Release Lever
Print Head
Assembly
& Bracket
Liner Rewind
Tube and Clip
Auxiliary Media Access
(Opening for Fan Fold &
External Media)
Ribbon Core
(Shipped mounted on
Ribbon Tube)
