Zebra 2746e - Page 7

Getting To Know
Your Printer
980412-001 Rev.A 3
Installation & Operation
Print Head
Platen
Roller
Peel/Tear
Bar
Liner "Peeler"
Gate
Controls
Media Roll
Holder
Platen
(Media Drive)
Roller Bracket
Ribbon Take-Up
Tube
Ribbon Supply
Tube
Rewind
Bracket
Print Width
Adjustment Knob
