4. Refer to Figure 17. Thread the media through the media guides.
NOTE: If the media guides must be changed to accommodate the
width of the media, turn the green media guide adjuster (refer to
Figure 17). The media guides should just touch, but not restrict,
the edges of the media.
5. Refer to Figure 17. Thread the media through the cutter unit.
6. Close the top cover and turn on the printer or press the feed button if
theprinterisalreadyon(see“AutoCalibration”onpage18formore
information).
16
Media
Guides
Media Guide Adjuster
Wide Media
Narrow Media
Figure 17
To Next Page
