Zebra FX7500 Deployment Guide

Setting Up Cloud Connect for RFID
21
Cloud Connect for RFID Configuration
The section describes the JSON object that can be sent to configure the interfaces.
For ease of explanation and representation, the JSON configuration file is split into three sections, each
representing the interface it configures.
• Control Section
• Data Section
• Management Section
NOTE: While importing the JSON configuration into the reader, it must be imported as a singe object.
Control Section
The control section of the Cloud Connect for RFID JSON configuration holds the JSON object for
configuring the Control interface. The JSON schema for the Control interface configuration is shown Figure
7.
Figure 7 JSON Schema for Control Interface Configuration
The Control interface can be configured to either connect to the cloud service (Zebra Data Services) or
allow local access. The sample configuration for either case is shown below.

Zebra FX7500 Specifications

General

Interface	USB
Product color	White
LED indicators	Activity, Power, Status
Housing material	Aluminium, Metal, Plastic
Battery type	-
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84719000

Weight and Dimensions

Depth	43.2 mm
Width	149.9 mm
Height	195.6 mm
Weight	860 g
