13
Getting Started
Loading Roll Media
8/4/10 GK420d™ User Guide 980608-001 Rev. C
3.
Pull the media so that it extends out of the front of the printer. Verify the roll turns freely.
The roll must not sit in the bottom of the media compartment. Verify that the media’s
printing surface is facing up.
4.
Push the media under both of the media guides.
5.
Close the printer. Press down until the cover snaps closed.
