Maintenance
Cleaning
8/4/10 GK420d™ User Guide 980608-001 Rev. C
6.
Make sure the bearings are on the shaft of the platen.
7.
Align the platen with the gear to the left and lower it into the printer’s bottom frame.
8.
Rotate the tabs back and snap them into place.
Allow the printer to dry for one minute before closing the dispenser door, media cover or
loading labels.
Other Printer Maintenance
There are no user level maintenance procedures beyond those detailed in this section. See the
Troubleshooting on page 59 for more information on diagnosing printer and print problems.
