Zebra GT800 - Key Printer Features

5
Introduction
What’s in the Box?
9/30/2014 GT800™ Thermal Transfer Printer User Guide P1032729-003Rev. A
Printer Features
Sensor
Peel Bar
Platen
Roller
Printhead
Movable Black Mark
Sensor
Ribbon Trailer
Sensor
Roll Holder and
Media Guides
Head-Up Sensor
(inside)
Pinch
Roller
Dispenser Door
(open)
Take Up
Spindles
Supply
Spindles
Ribbon Roll Holders
Dispenser Option
Web (Gap)
Sensor
Media Guide Stop
Adjustment
