Cutter Option
62
P1032729-003 Rev. A GT800™ Thermal Transfer Printer User Guide 9/30/2014
Loading Media with the Cutter Option
1. Open the printer. Remember that you need to pull the release latch levers toward the front
of the printer.
2. Adjust the media sensor’s position for labels or continuous media to the center position. If
the media has black marks (not full width black lines) or notches, then see Using the
Movable Black Mark Sensor on page 44
3. Open the media roll holders. Pull the media guides open with your free hand and place the
media roll on the roll holders and release the guides. Orient the media roll so that its
printing surface will be up as it passes over the platen (drive) roller.
To Next Page
