Maintenance
Cleaning
74
P1032729-003 Rev. A GT800™ Thermal Transfer Printer User Guide 9/30/2014
7. Align the platen with the gear to the left and lower it into the printer’s bottom frame.
8. Gently rotate both platen bearing latch release tabs down toward the rear of the printer and
snap them into the notches in both bearing wells.
Allow the printer to dry for one minute before closing the dispenser door, media cover or
loading labels.
Other Printer Maintenance
There are no user level maintenance procedures beyond those detailed in this section. See
the Troubleshooting on page 81 for more information on diagnosing printer and print
problems.
