Wireless Configuration
Configure Using the Network Setup Wizard
28
P1001060-006 Wireless Quick Start Guide 3/3/11
16. Observe the wireless status on the printer’s control panel, and confirm that you have set up
your printer for wireless connectivity. Printers that have an LCD display text or symbols
(see Table 2 and Table 3). The HC100 printer does not have an LCD, so the wireless status
is indicated by the control panel lights (see Table 4).
LCD Link Status and Wireless Signal Indicators
This section applies to printers and print engines other than the HC100 printer.
• Link Status Indicator (Table 2)
The wireless link status indicator appears at the bottom left of the LCD, providing a
real-time display of the printer’s network status.
• Wireless Signal Indicators (Table 3)
Depending on the printer model, press the right oval,
Plus (+), or the up arrow to
access and scroll through the wireless signal indicators on the LCD. For more
information on the control panel buttons on your printer, refer to your printer’s User
Guide.
Table 2 • Link Status Indicators
Status Indicator Meaning
cycling through characters
.oO
The wireless radio card is associated with the WLAN.
underscore
_
• The wireless radio card is not associated with the WLAN. Verify that
your printer’s wireless settings match those of the WLAN.
• The firmware on the wireless radio card may need to be updated.
blank • The printer is checking for a wired print server.
• The printer is running a wired print server.
• The wireless print server board is not installed or not installed correctly.
Table 3 • Wireless Signal Indicators
Wireless Signal Indicator Description
SIGNAL STRENGTH and
SIGNAL QUALITY
When these indicators display percentages, the wireless radio card is
communicating with the network. The higher the number is, the better the
connection is between the printer and the network.
If your printer indicates a signal strength but you cannot communicate with
the printer from your computer, move the printer to a different location to
try to get a better signal strength or signal quality. This situation could also
indicate that the printer is associated with, but not authenticated with, your
access point.
NOISE LEVEL
This number indicates any electrical interference with the wireless signal.
If your printer cannot communicate with the network and the noise level is
high, move the printer to a location that is free of interference.
