Zebra HC100 Wireless Quick Start Guide

PAX4 Series
Print Engine Installation
44
P1001060-006 Wireless Quick Start Guide 3/3/11
Figure 9 • Right Side View of Right-Hand Print Engine (170PAX4)
18.3 in. (465 mm)
0.394 in. (10.0 mm)
7.1 in. (180 mm)
MAX backing width
7.000 in. (177.8 mm)
MAX label width
8.500 in.
(215.9 mm)
10.398 in.
(264.1 mm)
19.700 in.
(500.4 mm)
(279.6 mm)
0.613 in.
(15.6 mm)
0.52 in.
(13.2 mm)
Ribbon and
media edge
First print
element
Mainframe
35° Ref
18.8 in. (478 mm)

Zebra HC100 Specifications

General

Product color	Black
