Accessories
Quick-Fit Hubs – 103939
46
P1028247-001 Rev. B KR203 Hardware Integrator Guide 10/26/2010
Quick-Fit Hubs – 103939
The Quick-Fit hubs are designed to use the printer’s mounting holes when mounting the
printer to a custom sheet metal surface 1.5 mm thick. When installed, the quick-fit hubs
allow quick installation to, and removal from the surface. See "Design Your Own
Mounting" on page 18 for more details.
Quick Fit Leaf Spring Retainer – 01473-000
The leaf spring retainer is designed to be used as a locking mechanism when using the
quick-fit hubs on a custom mounting surface.
