Accessories
Large Media Roll Adapter – P1026858
62
P1028247-001 Rev. B KR203 Hardware Integrator Guide 10/26/2010
Loading Media
1. Open the adapter tensioner assembly by pushing the locking tab .
2. Insert the media through the adapter and into the printer. For narrow media, the printer
will load automatically. For wide media, manual media loading may be required (see
"Loading Media" on page 40).
3. Close and lock the adapter tensioner assembly.
