Printer Overview
Printer Orientation
10
P1016701-001 Rev. B KR403 Hardware Integrator Guide 9/24/2010
Printer Orientation
Figure 3-2 • Printer Orientation
Table 3-1 • Printer Orientation
Output Horizontal Mount Output Vertical Mount
Media Exit and Present
Media Retract and Retain
(in kiosk)
Media Retract and Retain
(in kiosk)
Media Exit and Present
REAR
Media IN
FRONT
Media Out
LEFT
RIGHT
