67
Accessories
Quick-Fit Hubs – 103939
9/24/2010 KR403 Hardware Integrator Guide P1016701-001 Rev. B
Quick-Fit Hubs – 103939
The quick-fit hubs are designed to use the printer’s mounting holes when mounted on
a sheet metal surface 1.5 mm thick. See the "Design Your Own Mounting" on page 19 for
more details.
Quick Fit Leaf Spring Retainer – 01473-000
The leaf spring retainer is designed to be used as a locking mechanism when using the
quick-fit hubs on a custom mounting surface.
