44 P430i User’s Manual 980470-001 Rev. A
Technical Specifications
Card Specifications
Card Specifications
• Types: PVC or Composite
• Card Width/length ISO CR-80 - ISO 7810, 2.125" (54 mm) x 3.375" (86 mm)
• Option: Magnetic Stripe - ISO 7811
• Card thickness: 10-60 mil (0.25-1.5 mm) ± 10%
• Card feeder capacity: up to 100 cards (30mil) (Optional high-capacity feeder: up to 220 cards)
• Reject card bin capacity: 20 cards (30 mil)
• Card output hopper capacity: 100 cards (30mil)
Bar Codes
• Code 39, Code 128 B & C with & without check digit
• 2 of 5 and 2 of 5 interleaved
• UPC-A, EAN8, and EAN13
• PDF-417 2D bar code and other symbologies available via Windows printer driver
Fonts
• Arial and Arial Bold
• True Type fonts available via Windows Driver
Card Dimensions
ISO Standard 7810 Dimensions for Plain Card
0.125 in
Radius
(3.18 mm)
3.375 ± 0.01 in
(85.72 ± 0.25 mm)
2.125 ± 0.002 in
(53.98 ± 0.050 mm)
0.009 ~ 0.034 in
(0.23 ~ 0.84 mm)
