Zebra QLn220 User Manual

pg. 4
Wireless Congiguration QSG for 802.11n & Bluetooth Radios for Link-OS Mobile Printers
P1048352-001 Rev. C
continued
• Double click the Zebra Setup Utilities icon on your desk-
top to open.
• Connect a USB cable to both the printer and the PC or laptop
(as shown in Fig. 1).
• On the first ZSU screen, highlight the installed printer displayed
in the window and click on Con gure Printer Connectivity where
shown.
Connecting to the Wireless Network
• Select “Wireless” on the Connectivity Type screen and
click on the Next button.
• Select “DHCP” on the IP Address screen and click on the Next
button to proceed. (If “Static” is selected, you must enter the
IP address manually.)
Selecting Wireless Radio Type and Security Settings
• Select Radio Type from dropdown menu, i.e. 802.11 a/b/g/n and
click on the Next button.
Note: If you choose 802.11b/g/n or b/g, you will be limited to 2.4GHz band.
If you choose 802.11a/n, you will be limited to 5GHz band. If you choose 802.11a/b/
g/n, you will have access to both 2.4GHz and 5GHz bands.

Zebra QLn220 Specifications

General

Maximum resolution	203 DPI
Display	LCD
Product color	Black, White
RS-232 interface	Yes
Standard interfaces	Serial, USB 2.0, Ethernet
Optional connectivity	Ethernet
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Flash memory	256 MB
Certification	FCC 15, B, EN55022 B, EN60950, EN55024, VCCI B, EN55024, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, CE, UL, TUV, CSAMedia
Internal memory	128 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), EAN128, EAN13, EAN8, Interleaved 2/5, Matrix 2/5, PDF417, POSTNET, UPC-A, UPC-E
Processor frequency	400 MHz
Storage temperature (T-T)	-25 - 65 °C
Operating temperature (T-T)	-4 - 122 °F
Operating relative humidity (H-H)	10 - 90 %
Media thickness	0.0584 - 0.1397 mm
Maximum media length	813 mm
Maximum roll diameter	55.9 mm
Maximum media length (imperial)	32 \

Weight and Dimensions

Depth	173 mm
Width	117 mm
Height	84 mm
