12
QLn Series User Guide
9
8
11
4
13
10
1
2
3
5
6
7
14
12
Figure 2: QLn420 Shown
1 Platen Roller
2. Bar Sensor
3. Media Support Disks
4. Tear Bar
5. Label Presence Sensor
6. Peeler Lever
7. Peeler Bail
8. Latch Release Lever
9. Key Pad
10. Strap Post
11. Status Screen
12. Printhead
13. Media Cover
14. Gap Sensor
15. Belt Clip
16. Battery
17. DC Input
18. MAC Address Label
19. Docking Contacts
20. USB/ RS-232 Comm Ports
