________________________________________________________________
S4M
Internal Comparison
Product Guide 14 November 2005
S4M 2746e
Printer Features
Print Width, max. 4.1" (104mm) 4.09" (104mm)
Print Resolution 203/300 dpi 203 dpi
Max Print Speed 6ips (152mm) 6ips (152mm)
Standard RAM 8MB 512KB
STD Flash Memory 4MB 1MB
Media Features
Label Width, max. 4.5" (114mm) 4.5" (114mm)
Label Width, min. 0.75" (19.4mm) 1.12" (29mm)
Label Length, max 39" (991mm) 22" (559mm)
Label Length, min.
(Tear/Peel)
0.7" (17.8mm) / 0.5"
(12.7mm)
1.0" (25mm)/0.5"
(13mm)
Roll Size, O.D. 8" (203mm) 8.0" (203mm)
Max Ribbon Length 1476' (450m) 1160' (360m)
Interface
Serial Std Std
Parallel Std Std
Ethernet Optional Optional
Wireless Optional N/A
USB Interface Std Std
Throughput (Kmart Label)
1
st
Label/ 50 Unique Labels 1.1 / 52 sec N/A
Ribbon/Media Handling
Thermal Transfer Optional Standard
Ribbon Inside/Outside N/A N/A
Peel-Off w/o Liner Take-up Optional N/A
Peel-Off w/ Liner Take-up N/A Std
Cutter N/A Optional
Rewind N/A Std
Other
RFID Ready Option No No
LCD Display 2x14 N/A
Weight 27.2 lbs (12.4 kg) 28lbs (13kg)
Size (H x W x L)
11.7" x 10.7" x 18.8"
(295mm x 272mm x
477mm)
12.38" x 9.5" 16.75"
(314mm x 241mm x
425 mm)
List Price of Base Model $1145 $1495
S4M vs. 2746e
• The S4M printer’s
front control panel
features a streamlined
menu for simple
navigation, while its
proven side-loading
design eliminates
label and ribbon
threading for quick,
easy loading
• Built with the
ruggedness of a metal
enclosure and die-
cast frame, the S4M
offers Zebra quality
and reliability at a
competitive price.
• The S4M printer
offers faster
throughput than the
2746e, making it
comparable to other
modern Thermal
Printers in its price
class.
• The S4M printer
offers a larger
selection of
connectivity options
than the 2746e,
including wireless.
• The S4M printer is
easy to integrate in
existing applications
as it operates in EPL,
as well as ZPL, APL-
D and APL-I.
