Zebra S4M Product Guide

________________________________________________________________
S4M
Internal Comparison
Product Guide 15 November 2005
S4M Z4Mplus
Printer Features
Print Width, max. 4.1" (104mm) 4.1" (104mm)
Print Resolution 203/300 dpi 203/300 dpi
Max Print Speed 6 ips (152mm) 10ips (254mm)
Standard RAM 8MB 8MB
STD Flash Memory 4MB 4MB
Media Features
Label Width, max. 4.5" (114mm) 4.5" (114mm)
Label Width, min. 0.75" (19.4mm) 1.0" (25.4mm)
Label Length, max 39" (991mm) 39" (991mm)
Label Length, min.
(Tear/Peel)
0.7" (17.8mm) / 0.5"
(12.7mm)
.5" (12.7mm)/1.0”
Roll Size, O.D. 8" (203mm) 8.0" (203mm)
Max Ribbon Length 1476' (450m) 1476' (450m)
Interface
Serial Std Std
Parallel Std Std
Ethernet Optional Optional
Wireless Optional Optional
USB Interface Std N/A
Throughput (Kmart Label)
1
st
Label/ 50 Unique Labels 1.1 / 52 sec 0.78 / 52 sec
Ribbon/Media Handling
Thermal Transfer Optional Standard
Ribbon Inside/Outside N/A N/A
Peel-Off w/o Liner Take-up Optional Optional
Peel-Off w/ Liner Take-up N/A Optional
Cutter N/A Optional
Rewind N/A Optional
Other
RFID Ready Option No Yes
LCD Display 2x14 2X16
Weight 27.2 lbs (12.4 kg) 32.4 lbs (15 kg)
Size (H x W x L)
11.7" x 10.7" x 18.8"
(295mm x 272mm x
477mm)
13.3" x 10.9" x 18.7"
(338mm x 277mm x
475mm)
List Price of Base Model $1145 $1695
S4M vs. Z4Mplus
• Both the Z4Mplus and
the S4M printer are
reliable, metal printers
ideally suited for many
applications, including
product ID, receiving,
shipping, and
compliance labeling
• Both the Z4Mplus and
the S4M offer a large
selection of connectivity
options, including
internal Ethernet and
wireless
• The S4M printer has a
lower duty cycle than
the Z4Mplus, but much
higher than that of a
LP/TLP 2844. The S4M
is the ideal printer for
applications that need
more than a desktop,
yet don’t need the
horsepower of a
Z4Mplus
• The S4M printer is
slightly smaller than the
Z4Mplus making it a
good fit for certain
space constrained
environments such as
mobile carts
• The Z4Mplus printer
offers faster print speed
and thus faster
throughput for batch
printing and other high
speed applications
• The Z4Mplus printer
offers greater
application flexibility with
regard to Media
handling, supporting
options such as linear
take-up, full media
rewind and cutter.

Zebra S4M Specifications

General

Flash memory	4 MB
Internal memory	8 MB
Dimensions (WxDxH)	272 x 477 x 295 mm
Media types supported	continuous, die-cut, tag, black mark
Media thickness	0.076 - 0.15 mm
RS-232 ports	1
Standard interfaces	USB 2.0
Storage temperature (T-T)	5 - 40 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Weight	12400 g
