Load Media
6
13292L-001 Rev. A S4M Quick Reference Guide 9/21/05
6. Slide out the media guide.
7. Feed the media under the dancer assembly (1), through the slot in the transmissive
sensor (
2), and under the ribbon sensor (3). Push the media to the back of the transmissive
sensor.
8. Slide in the media guide until it just touches the edge of the media.
123
