Only use 6LR91 batteries within theIR foot switch.
Seite 22/69
Page 22/47JMA-Optic
3.7.3. Changing the battery
To replace the battery of the foot switch, proceed as follows:
Required Materials: Screw driver type PH 0x40
Battery type 6LR91/ 9Volt
Open the cover of the battery
with a screwdriver PH 0x40.
Remove the used battery.
Insert the new battery (type 6LR91) into the
battery holder and screw the cover back on.
Disposal of the used battery Refer to chapter:
7.5. Disposal, p. 34
