6.5 Specications
height on the back of the AIO 2400 that does not exceed the top
of the AIO 2400, you can proceed to install the Top Cover onto the
AIO 2400.
Capacity 2,400Wh
Battery Type
Wireless Type Bluetooth, Wi-Fi
PV Input Port MC4
PV Input Voltage Range 16V to 60V
PV Input 1 Power 400W
PV Input 1 Current 14A
PV Input 2 Power 800W
PV Input 2 Current 20A
Microinverter Output Port MC4
Microinverter Output Voltage Range 16V to 60V
Microinverter Output 1 Power 1,200W Max
Microinverter Output 1 Current 30A
Microinverter Output 2 Power 1,200W Max
Microinverter Output 2 Current 30A
Microinverter Output 1 + Output 2 Power Total 1,200W Max
Charging temperature
Discharging temperature
Dimensions 657x427x150 mm
Weight 31 kg (Without Bracket and Top Cover)
Waterproof rating IP65
Warranty 10 years
NO. Picture Name Part of a basic set / Optional (not included)
1 AIO 2400×1
2 Phillips Screwdriver
3 Top Cover × 1
4 Top Cover Screws M3*10 × 6
√
√
√
6.4 Installation Method for the Top Cover
