ZENEC Z-E2026 - Sound Settings

Technical modifications excepted. No liability granted for printing errors.
© Copyright 2015 · RevA / copy deadline: Q4-2015 · English
ZENEC · Bohrturmweg 1 · CH-5330 Bad Zurzach · Schweiz/Switzerland · Mail: support@zenec.com · www.zenec.com
KL 31 / Power GND B12 C15
KL 30 / Constant +12V PWR B15 C16
CAN-Bus B8 C41
CAN-Bus B9 C42
Loudspeaker rear right (+) B1 C1
Loudspeaker front right (+) B2 C2
Loudspeaker rear right (-) B5 C5
Loudspeaker front right (-) B6 C6
Loudspeaker rear left (+) B4 C4
Loudspeaker front left (+) B3 C3
Loudspeaker rear left (-) B8 C8
Loudspeaker front left (-) B7 C7
A1 KL 31 / Power GND
A2 KL 30 / Constant +12V PWR
A3
KL 15 /
Switched +12V PWR
A4
A5
Switched +12V amp PWR*
A6
A7
A8
A9 Loudspeaker rear right (+)
A10 Loudspeaker front right (+)
A11 Loudspeaker rear right (-)
A12 Loudspeaker front right (-)
A13 Loudspeaker rear left (+)
A14 Loudspeaker front left (+)
A15 Loudspeaker rear left (-)
A16 Loudspeaker front left (-)
CONNECTION DIAGRAM
A
D
AM/FM
DAB
GPS
E C
A10 A12 A14 A16A2 A4 A6 A8
A9 A11 A13 A15A1 A3 A5 A7
A9 Speaker Rear Right (+)
A10 Speaker Front Right (+)
A11 Speaker Rear Right (-)
A12 Speaker Front Right (-)
A13 Speaker Rear Left (+)
A14 Speaker Front Left (+)
A15 Speaker Rear Left (-)
A16
B1
B2
B5
B6
B4
B3
B8
B7
C1
C2
C5
C6
C4
C3
C8
C7Speaker Front Left (-)
A1 B12
B15
C15
C16
Q II Q IIIQ II Q III
KL 31 / Power GND
A2 KL 30 / Constant +12V PWR
A3 KL 15 / Switched +12V PWR
A4
A5 Switched +12V amplifier PWR*
A6
A7
A8 Reverse
Serial No.
EU Legal Representative: ACR S & V GmbH · Industriestr. 35 · D-79787 Lauchringen / Germany
*Manufactured under license from Dolby laboratories. "Dolby"
and the double-D symbol are trademarks of Dolby laboratories.
10R-05 1776
Rev. A
CLASS 1 LASER PRODUCT
12V DC / 10 A
NEGATIVE
16 PIN CONNECTOR
(DEVICE BACKSIDE)
Remove both loader locking screws BEFORE device installation
FM/AM ANTENNA IN:
SWITCHED 12V SUPPLY
*300mA max current
NAVICEIVER
Z-E2026
QUADLOCK II (
QII)
CONNECTORS
QUADLOCK III (QIII)
CONNECTORS
B1
B2
B3
B4
B5
B8
C1
C4
C5
C16
C15
C8
B6
B7
C2
C3
C6
C7
B15
B12
Camera
B
C A F D E
Reverse*
ext. Mic
Power max. 300mA
GND
Camera Audio
CVBS In* CVBS In*
Line In R
Line In L
Video In
Front Out R
Front Out L
Rear Out R
Rear Out L
SUB (4.2)
CNT (5.1)
Out
Subwoofer Out
Video Out 1 Video Out 2
Line Out R
Line Out L
*eingebaut miteinander verbunden
Line In R
Line In L
P. CNTR
Reverse*
A/V In A/V In Line Out M-Zone
Quadlock II
FUSE
Quadlock III
A10 A12 A14 A16A2 A4 A6 A8
A9 A11 A13 A15A1 A3 A5 A7
16 PIN CONNECTOR
(DEVICE BACKSIDE)
*Internally connected
QUADLOCK III (
QIII)
CONNECTORS
C1
C4
C5
C15
C16
C8
C2
C3
C6
C7
(see note on DAB antenna page 2)
