Connections
AM-FM Antenna Connections
Connect the supplied FM/AM antennas for listening to the radio.

Connect the AM loop antenna to the AM antenna terminals.

Connect he FM wire antenna to the FM antenna terminals.
otes

To prevent noise pickup, keep the AM loop antenna away from the DVD/CD receiver and other components.

Be sure to fully extend the FM wire antenna.

After connecting the FM wire antenna, keep it as horizontal as possible.
FM Wire aerial (supplied)
AM Loop aerial (supplied)
S/VIDEO OUT
COMPONENT
VIDEO OUT
PROGRESSIVE
SCAN
MONITOR OUT
