Specification
[General][CD/DVD][Video][Amplifier][Speakers]
[Supplied
Accessories]
Power supply Refer to main label
Power consumption Refer to main label
Mass 8.4 lbs
External dimensions (W x H x D) 14.1 x 2.9 x 12.3 inches
Operating conditions Temperature: 5°C to 35°C, Operation status: Horizontal
Operating humidity 5% to 85%
Laser Semiconductor laser, wavelength 650 nm
Signal system NTSC 525/60
Frequency response (audio) 200 Hz to 18 kHz
Signal-to-noise ratio (audio) More than 70 dB (1 kHz, NOP, 20 kHz LPF/A-Filter)
Dynamic range (audio) More than 65 dB
Harmonic distortion (audio) 1.0 % (1 kHz, at 12W position) (20 kHz LPF/A-Filter)
Video output 1.0 V (p-p), 75 Ω, negative sync., RCA jack
S-video output (Y) 1.0 V (p-p), 75 Ω, negative sync., Mini DIN 4-pin x 1
(C) 0.3 V (p-p), 75 Ω
Tuning Range 87.5 - 108.0 MHz or 65.0 - 74.0 MHz, 87.5 - 108.0 MHz
Intermediate Frequency 10.7 MHz
Signal-to Noise Ratio 55 dB (Mono)
Frequency Response 180 - 10,000 Hz
Tuning Range 522 - 1,611 kHz or 530 - 1,610 kHz
Intermediate Frequency 450 kHz
Stereo mode 30W + 30W (6 Ω at 1 kHz, THD 10 %)
Surround mode Front: 30W + 30W (THD 10 %)
Center*: 30W
Surround*: 30W + 30W (6Ω at 1 kHz, THD 10 %)
Subwoofer*: 50W (8Ω at 30 Hz, THD 10 %)
Outputs S-VIDEO
MONITOR
PHONES: (32 Ω, 20mW)
Satellite Speaker (LHS-D6245T) Passive Subwoofer (LHS-D6245W)
Type 1 Way 1 Speaker 1 Way 1 Speaker
Impedance 6 Ω 8 Ω
Frequency Response 130 - 20,000 Hz 50 - 1,500 Hz
Sound Pressure Level 85 dB/W (1m) 82 dB/W (1m)
Rated Input Power 30W 50W
Max. Input Power 60W 100W
Net Dimensions (W x H x D) 3.5 x 5.5 x 3.9 inches 6.2 x 13.7 x 13.5 inches
Net Weight 1.9 lbs 9.9 lbs
• Speakers . . . . . . . . . . . . . . . . . . . . . . . . . . .6 • Speaker cables . . . . . . . . . . . . . . . . . . . . . .5
• Remote control . . . . . . . . . . . . . . . . . . . . . .1 • Batteries (AAA) . . . . . . . . . . . . . . . . . . . . . . .2
• AM loop antenna . . . . . . . . . . . . . . . . . . . . .1 • FM antenna . . . . . . . . . . . . . . . . . . . . . . . . .1
❋ Designs and specifications are subject to change without notice.
(* Depending on the sound mode
settings and the source, there
may be no sound output.)
